Side Type Top / Pencil Type Hydraulic Breaker Hammers For Caterpillar/Komatsu/Kobelco/Hyundai/Volvo/Liebherr Excavators

  • 1
  • 2

Brand Name : Dopro

Model Number : DPSB400

Certification : ISO CE

Place of Origin : CHINA

MOQ : 1

Price : 100-2000

Supply Ability : 5000 Pcs Per Month

Delivery Time : 3-10Working Days

Packaging Details : Wooden Pallet /Wooded Box

Color : Customer Required,any color

Application : Mining,Crawler Excavator,Construction,breaking stone

Type : side type/top open type /box silenced type

After-sales service provided : Online support,Video technical support

Material : 42CrMo,20CrMo

Chisel diameter : 35-195mm

Condition : 100%new,100% new

Name : hydraulic breaker for backhoe loader,Hydraulic hammer rock breaker for excavator,silenced type road construction hydraulic breaker for mini excavator,Hydraulic breaking hammer

Part name : Hydraulic hammer rock breaker,Rock Breaker /Mini Hydraulic Hammer for Excavator and Wheel Loader

Product name : Soosan Hydraulic Breaker,Hydraulic Hammer Rock Breaker,Hammer For Excavator

Oem : yes

Oem/odm : Available,Acceptable

Suitable excavator : 4-16ton,3-7 ton

Contact Now

Side Type Top/Pencil Type Hydraulic Breaker Hammers for Caterpillar/Komatsu/Kobelco/Hyundai/Volvo/Liebherr Excavators





Excavator Hydraulic Impact Stone Demolition Breaker/Hammer


Application:

Mining:Mining,second-time breaking;
Metallurgy:Clearing slag,Demolition of furnace and foundation;
Road:Repairing,Breaking,Foundation work;
Railway:Tunneling,Demolition of bridge;
Construction:Demolition of building and reinforced concrete;
Ship repairing:Clearing clam and rust from the hull;
others:Breaking Frozen mud.



Standard Configurations:

1 Chisel * 2pcs;
2 Hydraulic Oil Hose * 2pcs;
3 Nitrogen Charging Kit With Pressure Gauge * 1 Set;
4 Nitrogen Bottle * 1pc ;
5 Tool Box With Necessary Maintenance Tools * 1 Set ;
6 User Manual * 1 pc.



Features of our hydraulic breakers:
1. Dopro  series became lighter, stronger and more powerful than ever.
2. Enlarged the diameter of T/Bolt improved its durability.
3. Switched box housing to bending desigh for more durability.
4. Redesigned chisel pin has improved durability.
5. Enlarged chisel's diameter improved more powerful impact.
6. High energy and impact frequency(high performance).
7. High-performance optimized hydraulic unit.
8. Low maintenance, less down, long using life.



Advantages:


1.Suitable for all models of excavator,skid steer loader and backhoe loader.
2.We will make or design hydraulic breakers as customer requests.
3.Because we are a manufacture and trading company ,the highest quality, competitive price and a perfect after-sales service should be provided to our customers.
4 High Strength and wear resistance steel plate adopted.
5. First-class quality: Korean technology used to guarantee the quality.

Package:

1. Inner is stretch film;
2. Outside is export wooden case;
3. As per customer's request.

Delivery:

1: Delivery Time : Usually 3-7days (1-5 sets) after full down payment ;
2: We can arrange ocean or air transportation according to your request .



SPECIFICATION
Model 　 DPSB400 DPSB450 DPSB530 DPSB680 DPSB750 DPSB1000
Suitable
Excavator		 Min ton 0.8 1.2 3 6 7 11
Max ton 2.5 3 5.5 9 14 17
Suitable ton 1 2 4 7 7 14
Tool
(MoilType)		 Weight Kg 4 6 9 20 25 59
Diameter mm 40 45 53 68 75 100
OperatingWeight
(Tool+M/C)		 　 Kg 70 90 120 250 380 765
　 h
IL		 158 200 330 605 649 1749
Height 　 mm 972 1071 1147 1349 1618 1934

Operating Pressure
(Breaker)		 　 bar 90～120 90～120 90～120 110~140 120～150 150～170
　 psi 1,160～1,450 1,160～1,450 1,305～1,740 1,377～1,885 1,450~2,030 2,175～2,465
Setting Pressure
(Machine)		 　 bar 150 150 150 170 180 200
　 psi 2175 2175 2175 2465 2610 2900
Impact Rate 　 bpm 800～1,400 700～1,200 600~1,100 500～900 400～800 350～700
BackHead Pressure
(N2-Gas)		 　 bar/psi 14/203 14/203 16/232 16/232 16/232 16/232
Required Oil Flow 　 l/min 15～30 20～40 25～50 40~70 50～90 80～110
　 　 　 　 　 　 　 　

SPECIFICATION
Model 　 DPSB1350 DPSB1400 DPSB1500 DPSB1550 DPSB1650 DPSB1750
Suitable
Excavator		 Min ton 16 18 25 28 20
0		 40
Max ton 21 26 30 25 45 55
Suitable ton 20 24 24 34 40 50
Tool
(MoilType)		 Weight Kg 125 129 129 193 233 311
Diameter mm 135 140 140 155 165 175
Operating Weight
(Tool+M/C)		 　 Kg 1462 1740 2144 2413 2650 3857
　 lb 3190 3916 3916 5940 6589 9020
Height 　 mm 2295 2429 2623 2776 2953 3189

Operating Pressure
(Breaker)		 　 bar 160～180 160～180 160～180 160～180 160～180 160～180
　 psi 2,320～2,610 2,320～2,610 2,320～2,610 2,320～2,610 2,276~2,702 2,276～2,845

Setting Pressure
(Machine)		 　 bar 210 210 210 220 240 240
　 psi 3045 3045 3045 3190 3480 3480
Impact Rate 　 bpm 350～600 350～500 300～450 300～450 250～400 150～350
Back Head Pressure
(N2-Gas)		 　 bar/psi 16/232 16/232 16/232 16/232 17/246 18/261
Required Oil Flow 　 l/min 100～150 120～180 150～210 180～240 200～260 200～290
　 　 　 　 　 　 　 　
